Product Details
Smartaegis Access Control Software
SMARTAEGIS ACS software is a cutting-edge access control software designed to offer unmatched flexibility, security, and convenience. Compatible with a wide range of credentials—including keycards, fobs, smartwatches, and mobile apps—SMARTAEGIS empowers users to manage access from anywhere, on any device, 24/7. With real-time activity reports, alarm management, and mustering features, it ensures safety and situational awareness at all times. Built for the future, the platform offers unlimited scalability and benefits from remote, automatic software updates to stay ahead of evolving security needs.
Download Datasheet
Key Features of the Smartaegis-WT2053 Series
Heavy Duty Gate Arm Barrier
- Non-Isokinetic Double Dead Point Four-Link Mechanism
- Ensures smooth, stable arm movement.
- Group Spring Balancing
- Reduces motor load and extends lifespan
- Hall Limit Sensors
- Combined with structural limits for precise positioning.
- Magnet-Based Limit Adjustment
- Non-contact horizontal/vertical calibration.
- CNC-Processed Drive Parts
- High-precision components; no cast parts.
- Fire Protection Interfaces
- Built-in circuits for emergency shutdown.
- CNC-Processed Drive Parts
- High-precision components; no cast parts.
- Infrared/Pressure Wave Radars
- Obstacle detection for automatic stoppage.
- Waterproof & Moisture-Proof Design
- Suitable for harsh environments.
Structural Design
Head: Houses motor, gearbox, and Hall limit sensors.
Cam Door: Reinforced door for secure alignment.
Chassis: Constructed from 2.0mm cold steel; critical parts use ≥4.0mm steel for durability.
Barrier Arm Rest Stand: Heavy-duty stand included for stable arm placement in the resting position. Made of galvanized steel to resist corrosion.
Lightweight alloy with corrosion-resistant coating; adjustable length (3–6 meters).
Technical Specifications
| Features | Specification | |
|---|---|---|
| Protection Level | IP64 (dust-tight and water-resistant) | |
| Voltage | 220V ±10% or 110V ±10%, 50/60Hz | |
| Motor | 220V/9W pure copper motor with high-precision turbine gearbox | |
| Remote Control Distance | ≥10 meters | |
| Net Weight | 80 kg | |
| Arm Speed Adjustment | 1.5s, 3.0s, 4.5s, or 6.0s (4 preset speeds) | |
| Boom Length | Adjustable from 3 meters to 6 meters (customizable during installation) | |
| Chassis Dimensions | 340 × 250 × 1030 mm | |
| Operating Temperature | -30°C to +80°C | |
| Relative Humidity | < 90% |
